COM.LoRaWAN Module 915MHz (ASR6501) with antenna
Product Description The module uses the ASR6501 system, which permits long-distance communication while consuming very little power and having a high sensitivity. The LoRaWAN protocol stack is integrated, and a serial communication interface is used. It can be implemented as a collection note to access huge data. Product Features ASR6501 Supported US915 SMA antenna Communication […]
Maker & Coder Subscriber? Login to get your discount
Product Description
The module uses the ASR6501 system, which permits long-distance communication while consuming very little power and having a high sensitivity. The LoRaWAN protocol stack is integrated, and a serial communication interface is used. It can be implemented as a collection note to access huge data.
Product Features
- ASR6501
- Supported US915
- SMA antenna
- Communication interface: UART
- Command protocol: AT command
Applications
- Automatic remote meter reading
- Intelligent traffic intelligent parking lot
- Remote irrigation and environmental monitoring
Specifications
| Communication chip | ASR6501 |
| Operating Frequency | 915MHz |
| LoRaWAN Version | v1.0.1 |
| Minimum Receive Sensitivity | -137dBm (SF=12/BW=125KHz) |
| Maximum transmit power | +21dBm |
| Communication | UART 115200bps |
| Net Weight | 12.8g |
| Gross Weight | 45g |
| Product size | 71.5 * 24 * 8mm |
